XING NANO 0803 Motor (w/Plug)

Description

Specifications

Model: XING NANO 0803

KV: 17000KV/22000KV

Input Voltage: 1S

Dimension: Ф10.8*14.4mm

Weight(included wire): 2.1g

Interphase Resistance: 58mΩ

Peak Current: 4.11A/5.81A

Max Watt: 16.4W/23.2W

Mounting Holes: 6*6 φ1.4mm

Rotor Specifications: Segmented Bell

Shaft Diameter: 1mm

Shaft Protruding Length: 5.5mm

Magnet: N52H Curved

Configuration: 9N12P

Bearing Type: NSK

Winding: Single Strand copper winding

Packing List

1X XING NANO 0803 Brushless Motor

1X Motor Screw Pack
